YS-461K-V Computerized Air Permeability Tester for Paper and Board

【Product Overview】

Designed for testing the air permeability of diaphragms and various membrane materials, including battery separators, mica tapes, breathable films, thin sheets, paper, and related polymer products.

【Compliance Standards】

GB/T 36363-2018 Polyolefin Separators for Lithium-Ion Batteries

ISO 5636, SJ/T 1071.9, and other international standards

GB/T 458, ISO 5636/2, QB/T 1667, GB/T 22819, GB/T 23227, ISO 2965, YC/T 172, GB/T 12655, ISO 5636/3, ISO 5636/5, GB/T 20042.7-2014, GB/T 36363-2018

【Key Features】

1.One-Click Testing: Fully automated operation.

2.TFT LCD Touchscreen: Intuitive user interface.

3.Flat UI Design: Zero-navigation-depth interface for effortless operation.

4.Pneumatic Sample Clamping: Secure and efficient sample fixation.

5.Multi-Unit Display: Results shown in s/100ml and μm/(Pa·s).

6.Built-in Thermal Printer: Onboard report generation.

7.Automatic Overload Protection: Ensures equipment and sample safety.

8.Standard Communication Interface: Supports data export and integration.

【Technical Specifications】

1.Measurement Range: 10–15,000 s/100ml (standard configuration); other ranges available upon request.

2.Resolution: 0.1 s/100ml.

3.Sample Capacity: 1 sample per test.

4.Pressure Range: 5 kPa (optional: 10 kPa, 20 kPa).

5.Pressure Accuracy: 0.0001 kPa.

6.Test Area: 1.0 in² (6.45 cm²).

7.Sample Thickness: ≤5 mm.

8.Test Gas: Clean air (user-supplied).

9.Gas Supply Pressure: 0.3–1.0 MPa.

10.Interface Size: Ф6 mm.

11.Dimensions (L×D×H): 370 mm × 320 mm × 450 mm.

12.Power Supply: AC 220 V, 50 Hz.

13.Net Weight: 20 kg.

【Test Principle】

Based on the differential pressure method, the instrument measures air permeability by placing a pre-conditioned sample between upper and lower measurement surfaces. A constant pressure differential is applied across the sample, driving air flow from the high-pressure side to the low-pressure side. The permeability is calculated based on the flow rate, pressure differential, and test area. Results are expressed as the average air flow rate per unit area under specified conditions, in micrometers per Pascal-second [1 μm/(Pa·s) = 1 mL/(m²·Pa·s)].
